Description
A reducing coupling joins two pipes of different sizes in a straight line. It has a larger socket or thread at one end and a smaller one at the other. Therefore, the line can step down without a separate reducer. We stock reducing couplings at our showroom in Nad Al Hamar, Dubai, for same-day collection across the UAE.
First, note both pipe sizes, for example 1″ x 3/4″. Next, choose the end type: threaded for quick fitting, or socket weld for high pressure. Finally, choose carbon steel A105 for oil and steam, or stainless steel 316L for chemicals and seawater. In addition, we can supply matching nipples and bushings for the same line.
Why Choose Our Reducing Coupling
- Compact joint: One fitting does the job of a coupling and a bushing.
- High pressure: Forged couplings come in Class 3000 and Class 6000.
- Two end styles: Threaded NPT or BSPT, or socket weld for welded lines.
- Traceable steel: In addition, EN 10204 Type 3.1 certificates are available on request.
Reducing Coupling: Sizes and Standards
| Parameter | Specification |
|---|---|
| Standard | ASME B16.11, BS 3799 |
| Pressure classes | Class 3000 and Class 6000 |
| Ends | Female NPT, female BSPT or socket weld |
| Sizes | 1/4″ to 4″, all common reductions |
| Materials | Carbon steel ASTM A105; stainless steel ASTM A182 F304/304L, F316/316L; GI on request |
Where They Are Used
- Hydraulic lines: for example, stepping down to a valve block.
- Steam and condensate: for instance, trap and drain lines.
- Water and air: such as pump outlets and air mains.
- Process plants: in particular, small-bore instrument lines.
Order from Our Dubai Showroom
Firstly, visit Showroom No. 14, Nad Al Hamar, Dubai to collect from the counter. Alternatively, send your list to +971 4 285 1521 or on WhatsApp at +971 50 486 7233 for a same-day quote. You can also see the socket coupling, our high pressure fittings or the ASME B16.11 standard.
