A Straub clamp is a stainless steel pipe coupling that joins two plain-end pipes. It has a stainless casing, a rubber sealing sleeve and two bolts. As a result, you can join or repair a pipe in minutes, with no welding or threading. We stock Straub clamp style couplings at our showroom in Nad Al Hamar, Dubai.
First, measure the outside diameter of the pipe exactly, because each clamp covers a small range. Next, choose a grip type if the pipe must not pull apart, or a flex type where it can move. Finally, choose EPDM seals for water or NBR seals for oil and fuel. In addition, the clamp needs no special tools, only a torque wrench.
Why Choose Our Straub Clamp
- No pipe preparation: Plain-end pipes need no threads, grooves or welds.
- Fast repairs: You can fit it over a crack or leak on a live job.
- Joins different pipes: It joins steel, stainless, copper and plastic pipes.
- Rust resistant: In addition, the stainless casing suits wet and coastal areas.
Straub Clamp: Specifications
| Parameter | Specification |
|---|---|
| Casing | Stainless steel 304 or 316 |
| Seal | EPDM (water), NBR (oil and fuel) |
| Types | Grip (axial restraint), flex (no restraint), repair |
| Sizes | From about 26 mm to 300 mm pipe OD |
| Bolts | Stainless steel |
Where They Are Used
- Water lines: for example, leak repairs and pump connections.
- Marine: for instance, seawater and bilge pipes.
- HVAC: such as chilled water lines.
- Industry: in particular, compressed air and process lines.
Order from Our Dubai Showroom
Firstly, visit Showroom No. 14, Nad Al Hamar, Dubai to collect from the counter. Alternatively, send your list to +971 4 285 1521 or on WhatsApp at +971 50 486 7233 for a same-day quote. You can also see our VJ couplings, all clamps and couplings or read about pipe fittings.
