Description
Forged Hex Head Plug – High Pressure CL3000 CL6000 Socket Weld are heavy-wall forged steel fittings engineered for severe service piping networks operating under high static pressure, intense vibration, and severe thermal cycles. Fitting World Trading LLC stocks and distributes premium ASME B16.11 and BS 3799 forged fittings—including Bothwell brand high-pressure forged lines—from our showroom in Nad Al Hamar, Dubai, serving industrial plants, mechanical contractors, and marine operations throughout the GCC.
Forged from high-grade ASTM A105 carbon steel and ASTM A182 F316L/F304L stainless steel, our forged fitting inventory is available in both Threaded (NPT to ANSI B1.20.1 and BSPT to BS 21) and Socket Weld (SW) connection styles across 3000# and 6000# pressure classes, ensuring maximum joint strength and zero leak paths in compact piping skids.
Key Technical & Engineering Advantages
- Exceptional Pressure Resistance: Heavy forged body geometry easily contains static and dynamic surge pressures up to Class 3000 (3,000 PSI) and Class 6000 (6,000 PSI).
- Precision CNC Machined Threads: Tapered NPT and BSPT threads are precision-cut with sharp crests and roots to ensure tight mechanical engagement and reliable sealant retention.
- Deep Socket Weld Pockets: Accurately bored socket weld recesses provide stable pipe alignment and standardized thermal expansion gaps prior to fillet welding.
- Homogeneous Forging Density: Solid die-forged construction eliminates porosity, sand inclusions, and casting voids, making it suitable for hazardous gas and hydraulic service.
Dimensional Specifications & Standards
| Parameter | Technical Specification & Range |
|---|---|
| Manufacturing Standards | ASME B16.11, BS 3799, MSS-SP-79 / 83 / 95, DIN 2999 |
| Pressure Ratings | Class 2000, Class 3000 (3000#), Class 6000 (6000#), Class 9000 |
| Size Availability | 1/8″ NB through 4″ NB (Immediate Dubai Showroom Stock) |
| Connection End Styles | Female NPT, Female BSPT, Socket Weld (SW), Male Threaded |
| Material Metallurgy | Forged Carbon Steel ASTM A105/A105N, Stainless Steel ASTM A182 F316/316L, F304/304L |
| Certification | Supplied with 100% material traceability and EN 10204 Type 3.1 Mill Test Certificates |
Project Applications Across Critical Systems
- High-Pressure Hydraulic & Lube Oil Lines: Heavy equipment piping, compressor discharge lines, and hydraulic power units.
- Chemical & Hydrocarbon Sampling Systems: Instrumentation take-offs, impulse piping, and chemical injection manifolds.
- Steam & Boiler Auxiliary Piping: High-pressure steam traps, boiler blowdown lines, and condensate drain headers.
- Fire Protection & Water Deluge: High-pressure sprinkler mains and deluge valve trim assemblies.
Dubai Showroom Trade Counter & Fast Procurement
Direct trade counter collection is available at Showroom No. 14, Nad Al Hamar, Dubai. For contractor packaging, bulk fittings schedules, or same-day local delivery across the UAE, reach our engineering sales team on +971 4 285 1521 or via WhatsApp on +971 50 486 7233.
